Temperature Sensor Probes
A temperature and humidity probe is a type of temperature and humidity sensor. We offer many different types of temperature and humidity sensor probes and these are used for different applications across a whole host of industries. Our temperature sensor probes are for sht20, sht30, sht35 sensors. The price is cheap, the workmanship is excellent, and it can effectively be waterproof and dustproof.
- Model: RS-SHT-*-EX
- MOQ: 1 PCS
- Delivery date: within 24 hours
- Price: $4.5~$33.9
Temperature and humidity sensor probe types
We offer high accuracy sht20 sensor probes, sht30 sensor probes and sht35 sensor probes. Our temperature and humidity sensor probe can be used in all industrial environments. It is made of high-temperature and corrosion-resistant polymer materials, uses special potting technology to ensure that the probe can work normally in high temperature and high humidity environments. The temperature and humdiity sensor probe can choose I2C output, rs485 output, or voltage output. The signal is stable, free from the interference of electromagnetic waves on-site.
Our temperature and humidity sensor probes and size
sht 20, sht30, sht35 sensor parameters
sht20 sensor datasheet
sht30 sensor datasheet
sht35 sensor datasheet
sht20 sensor datasheet
| Model | SHT20 |
| Power supply voltage range | 2.1-3.6V |
| Output | I2C digital/PWM, SDM/Analog voltage interface |
| Energy consumption | 3.2μm (8-bit measurement, once/s |
| Relative humidity working range | 0~100%RH |
| Temperature working range | Temp -40~125°C (-104~257°F) |
| Humidity response time | 8s |
| Temperature accuracy | ±0.3℃ (25℃) |
| Humidity accuracy | ±3%RH (25℃, 60%RH) |
sht30 sensor datasheet
| Model | SHT30 |
| Size | 2.5*2.5*0.9mm |
| Output | I2C, voltage output |
| Power supply voltage range | 2.4-5.5V |
| Energy consumption | 4.8μm (low repeatability at 2.4V, once/s) |
| Humidity working range | 0-100%RH |
| Temperature working range | Temp -40~125°C (-104~257°F) |
| Humidity response time | 8s (tau63%) |
| Temperature accuracy | ±0.3℃ (25℃) |
| Humidity accuracy | ±3%RH（25℃, 60%RH） |
sht35 sensor datasheet
| Model | SHT35 |
| Size | 2.5*2.5*0.9 mm |
| Output | I2C, voltage output |
| Power supply voltage range | 2.4-5.5V |
| Energy consumption | 4.8μm (low repeatability at 2.4V, once/s) |
| Humidity working range | 0~100%RH |
| Temperature working range | Temp -40~125°C (-104~257°F) |
| Humidity response time | 8s (tau63%) |
| Temperature accuracy | ±0.3℃（25℃） |
| Humidity accuracy | ±3%RH (25℃, 60%RH) |
Featured temperature and humidity sensor probes
Model: SHT-70
Probe length: 70mm
Wire length: default 50cm, can be lengthened
Applicable sensors: sht20, sht30, sht35
Model: SHT-58
Probe length: 58mm
Wire length: default 50cm, can be lengthened
Applicable sensors: sht20, sht30, sht35
Model: SHT-77
Probe length: 77mm
Wire length: default 50cm, can be lengthened
Applicable sensors: sht20, sht30, sht35
Hardcover temperature and humidity sensor probe
Model: SHT-68
Probe length: 68mm
Wire length: default 50cm, line length can be customized
Applicable sensors: sht20, sht30, sht35
High temperature and humidity sensor probe
Model: SHT20-59-B
Probe length: 59mm
Wire length: 50cm
Applicable sensors: sht20, sht30, sht35
Temperature range: -40~+120°C
Quarter pipe thread temperature and humdiity sensor probe
Model: sht*-155-LW
Probe length: 155mm
Applicable sensors: sht20, sht30, sht35
High sensitivity temperature and humidity sensor probe
Model: SHT-70
Probe length: 70mm
Wire length: 50cm, the line length can be customized
Applicable sensors: sht20, sht30, sht35
